Developer Playground

About Kafka Basic

Updated: March 31, 2025

Topics

  • A category or feed name to which records are published
  • Identified by unique names within a Kafka cluster
  • Store messages in various formats (JSON, Avro, Protobuf, text, binary, custom)
  • Split into partitions for distributed data scaling
  • Configured with replication factor for fault tolerance
  • Support configurable retention policies (time/size based)
  • Immutable append-only logs - once written, cannot be modified
  • Names are case-sensitive (alphanumeric, dots, underscores, hyphens)
  • Internal topics: __consumer_offsets and __transaction_state
Kafka Topics and Partitions Topic A Partition 0 0 1 2 3 Partition 1 0 1 2 Topic B Partition 0 0 1 2 3 4 Partition 1 0 1 Message with offset

Partitions &Offsets

  • Topics have one or multiple partitions for parallel processing
  • Each partition is an ordered, immutable sequence of records
  • Messages in a partition are strictly ordered with sequential offsets
  • Offsets are partition-specific identifiers that are immutable
  • Each partition starts with offset 0
  • Default retention: 7 days (configurable by time/size)
  • Oldest messages are removed when retention limits are reached
  • Partitions are distributed across brokers for load balancing
  • Each has a leader broker and zero or more follower brokers
  • Partition count can be increased but not decreased after creation

Producer

  • Write (publish) data to Kafka topics
  • Can specify partition or let Kafka handle assignment
  • Message components: key, value, headers, timestamp
  • Compression options: none (default), gzip, snappy, lz4, zstd
  • Timestamp options: system time (default) or custom
  • Support for retries, idempotence, and exactly-once semantics (since 2.8)

Partitioning strategies:

  • Null key: round-robin distribution
  • Non-null key: consistent hashing (murmur2)
  • Custom partitioning possible

Acknowledgment modes (acks):

  • acks=0: No acknowledgment (fire and forget)
  • acks=1: Leader acknowledgment only (default)
  • acks=all/-1: Full acknowledgment from leader and all in-sync replicas
Kafka Producers and Consumers Producer 1 Producer 2 Kafka Cluster Topic Partition 0 Partition 1 Partition 2 Consumer Group Consumer 1 Consumer 2 Consumer 3 Key-based routing Acks, compression Ordered messages in each partition Immutable offsets One partition per consumer within group

Consumers

  • Pull (fetch) data from Kafka topics
  • Read messages in exact write order within each partition
  • Use deserializers for various data formats
  • Maintain position by tracking last consumed offset
  • Offset reset policies: earliest, latest, none
  • Configurable fetch settings for throughput vs. latency optimization

Consumer Groups

  • Organized for parallel processing
  • Each consumer assigned exclusive partitions within a group
  • Dynamic rebalancing when consumers join/leave
  • Inactive consumers if more consumers than partitions
  • Identified by unique group.id
  • Offsets committed to __consumer_offsets topic
  • Managed by a group coordinator broker
  • Partition assignment strategies: Range, RoundRobin, Sticky, CooperativeSticky
Kafka Consumer Groups and Delivery Semantics Kafka Topic Partition 0 Partition 1 Partition 2 Partition 3 Group A Consumer A1 Consumer A2 Consumer A3 Consumer A4 Group B Consumer B1 Consumer B2 Delivery Semantics • At least once (default): Commit after processing, possible duplicates • At most once: Commit on receive, possible data loss • Exactly once: Transactions API, no duplicates, no loss Each consumer handles 2 partitions Topic with 4 partitions 1 partition per consumer within the group Offsets stored in __consumer_offsets topic Group A connections Group B connections

Delivery semantics for consumers

At least once (default):

  • Commit after processing
  • May cause duplicates if failure occurs
  • Requires idempotent consumers

At most once:

  • Commit on receive, before processing
  • No reprocessing on failure, potential data loss

Exactly once:

  • Via Kafka Transactions API
  • Requires idempotent producers and transactional consumers
  • Primarily for Kafka-to-Kafka workflows

Kafka brokers

  • Distributed system of multiple servers (3-100+)
  • Each identified by integer ID
  • Connect via bootstrap servers
  • Manage partitions, handle requests, manage replication
  • Automatic leadership transfer on failure
  • Controller broker manages administrative operations
Kafka Brokers and Replication Broker 1 (id: 101) Topic A - P0 (Leader) Topic A - P1 (Follower) Topic B - P1 (Follower) Broker 2 (id: 102) Topic A - P0 (Follower) Topic A - P1 (Leader) Topic B - P0 (Follower) Broker 3 (id: 103) Topic A - P0 (Follower) Topic A - P1 (Follower) Topic B - P0 (Leader) Replication Information • Replication Factor: 3 (each partition has 3 copies across brokers) • For each partition, one broker is the leader, others are followers (ISR) • With RF=3, cluster can tolerate 2 broker failures without data loss Leader Partition Follower Partition Controller Broker Manages administrative tasks and leadership elections

Topic replication factor

  • Replication factor = number of copies per partition
  • Recommended: factor of 3 for production
  • Must be ≤ number of brokers
  • Set at topic level, can differ between topics
  • With factor N, tolerate N-1 broker failures

Concept of Leader for a Partition

  • One leader per partition handles all reads/writes
  • Followers passively replicate from leader
  • In-Sync Replicas (ISR) = leader + caught-up followers
  • With 3 partitions, RF=3, 3 brokers: each partition has ISR=3
  • Automatic leadership transfer on failure
  • Controller manages elections

Kafka Topic durability

  • Replication factor N tolerates N-1 broker failures
  • Enhanced by min.insync.replicas setting
  • Strongest guarantees: RF=3, min.insync.replicas=2, acks=all
  • Trade-off: higher durability vs. latency/throughput
Kafka: Zookeeper vs KRaft Zookeeper-based Architecture (Before Kafka 4.0) Zookeeper Ensemble ZK1 ZK2 ZK3 Kafka Brokers B1 B2 B3 KRaft Architecture (Kafka 4.0+) Kafka Brokers with KRaft KRaft Controller Quorum KR1 KR2 KR3 B1 B2 B3 Kafka Version Timeline v2.8 KRaft Preview v3.0 KRaft Supported v3.3 KRaft Production-Ready v4.0 Zookeeper Removed Zookeeper: Manages metadata, broker coordination, leader election KRaft: Self-managed consensus, simplified architecture

Zookeeper

  • Managed metadata and broker coordination (historically)
  • Handled broker registration, configurations, elections
  • Stored consumer offsets until 0.10
  • Required until Kafka 2.7
  • KRaft mode preview in 2.8, official in 3.0
  • Production-ready in 3.3.0
  • Removed completely in 4.0
  • Typically used 3-5 nodes (7 for large clusters)
  • Leader-follower ensemble with quorum consensus
